Wave '12' Bengal Performance Rotor And Adapter Assembly Instruction ~ Bengal performance brake system has been designed for bicycle use only!! The use on any other kind of vehicles will not be warranted by Bengal performance. Improper installation could cause sever or fatal injuries. ~ Before each ride, always check your brakes for proper function and the brake pads for wear. When you rider, always wear a helmet. ~ It is very important to understand how to operate a brake system; any inappropriate use may result in loss f control, accident, or injury. ~ A qualified technician with the proper tools should perform installation of the disc brake components. Mounting The Rotor To The Hub USE FOR Rotor screws : Tools required Torx T25 Driver ~ Clean the disc and the hub-mounting surface with alcohol. Warning : Do not use disc brake cleaners. ~ Place the roto on the mounting surface of the hub, and make sure the arrow on the rotor is pointing the same direction of rotation in which the wheel move forwards. ~ Fasten M5 *P0.8* 10 rotor screws with Torx T25 driver in sequence, torque to 6-8N-m (53-71 in. lbs) USE FOR Center Lock : Tools required Socket ~ Place the rotor on the mounting surface of the hub and fasten lock ring by socket with tightening torque at 35-40N-m (310-354 in. lbs) Weight OD-160L 160mm/6" 104g OD-180L 180mm/7" 134g Finish Color : Red(RD) / Black (BK) / Royal-Blue(RB) / Gold(GD) / Grinding(GR) Package including : 1 x rotor, 6 x screws Made in Taiwan Please visit our website at http://www.ecomtb.com.my OR https://shopee.com.my/eco_mtb ** There is 1-3cm errors due to manual measurement. Please kindly understand. ** Actual product colour may slightly vary due to photographic lighting sources or your monitor settings. ** WE DO NOT DO COD ** ONLINE ONLY ** We support original products only. ** PRICE INDICATED IS ALREADY BEST PRICE, EXCLUDE COURIER
